The blower and EC-filter is an under- and over-pressure filter, designed for continuous operation. Constructed as a self-supporting sheet metal construction. The round design ensures great strength combined with low weight.
Surface Powder coated to corrosion class C3 cf. ISO 12944.
Inlet The Blower and Jet filters are fitted with 180º tangential inlets to ensure effective sorting of heavy materials before the process air passes through the filter medium. BF-34, 36, 55, 60, and 90-filters are also available with total separators. Standard height is 1000 mm, with the inlet at 90ºC. This type of inlet is used in plants in which the process air contains heavy and sharp articles to prevent them from coming into contact with the filter medium.
Cleaning system BF-36, 60, 90 ET filters are supplied with PowerPulse®. BF-8, 12, 20, 34, 55 filters are supplied with EC-cleaning.
Discharge system Conical or scraper bottoms are available for the discharge system, but silo filter is also available.
Blower and EC-filters
ATEX Choose between side venting or JKF’s specially developed VFV® explosion relief venting, which vents explosion pressure vertically through the filter top.
Operating range Pressure: +/- 5000 Pa
Filter area: 7.7-200 m²
Max. operating temperature: 70ºC
Min. operating temperature: -20ºC (available for: -40 ºC)
Connection Gear motor Blower-cleaning: 0,25 kW, 1 x 230 V, 50 Hz, 0,1 A
Gear motor PowerPulse® cleaning system: 0.12 kW, 15.6 min-1, 3 x 230 V, 50 Hz, 0.7 A
Gear motor scraper bottom: Type 20: 0.25 kW, 15.7 min-1, 3 x 400 V, 50 Hz, 1.1 A
Type 34, 36: 0.55 kW, 11.0 min-1, 3 x 400 V, 50 Hz, 1.7 A
Type 55, 60, and 90: 0.75 kW, 11.0 min-1, 3 x 400 V, 50 Hz, 2.2 A
Inductive sensor, scraper bottom: 24 VDC
PowerPulse-® ECOTROL® filter control system, BF-CT-ET: 0.6 kW, 1 x 230 V, 50 Hz, 1.9 A
External compressed air - PowerPulse®: 5 bar, min. 350 Nl/min.
Air quality according to ISO 8573-1: 2010 [5:3:4]
External connection: ¼” internal thread.
Noise Noise level during cleaning measured 5 m from ground level:
EC: 70.0 dBA
PowerPulse®: 70.4 dBA
Accessories Ladder/gangway: Ladder/gangway designed according to ISO/EN/DIN 14122.3/4 and available in several configurations.
- Ladder with gangway, front-mounted
- Ladder with double gangway, front-mounted
- Monitoring equipment for explosion membrane
Door contacts: 2.3 (close-before-switch-contact) in accordance with EN50047, IP67 NC contact.
Type designations Filters are type-designated using a combination of letters and numbers separated by hyphens and spaces. Designation BF-36CT-ET S VFV 3.0-R therefore describes a Blower filter with 36 filter bags, PowerPulse® cleaning system with ET, scraper bottom, vertical explosion relief venting, 3 m filter bag, and right inlet.
